7300 Raised Rib Modular Plastic Conveyor Belt

Short Description:

7300 raised rib modular plastic conveyor belt application in conveyor for vegetable、fruits industry and meat processing.

Product Detail

Product Tags

Parameter


Modular Type

7300 Raised Rib

Standard Width(mm)

76.2 152.4 228.6 304.8 381 457.2 533.4 609.6 685.8 76.2*N

(N,n will increase as integer multiplication;

due to different material shrinkage,Actual will be lower than standard width)

Non-standard Width

W=76.2*N+12.7*n

Pitch(mm)

25.4

Belt Material

POM/PP

Pin Material

POM/PP/PA6

Pin Diameter

5mm

Work Load

POM:22000 PP:14000

Temperature

POM:-5C°~ 80C° PP:+5C°~104C°

Open Area

34%

Reverse Radius(mm)

30

Belt Weight(kg/㎡)

8.9

7300 Machined Sprockets


Machined Sprockets

Teeth

Pitch Diametet(mm)

Outside Diameter

Bore Size

Other Type

mm

Inch

mm

Inch

mm

Available On request

By Machined

1-2540-12T

12

98.1

3.86

96.8

3.81

25 30 35 40 50

1-2540-18T

18

146.3

5.75

146.1

5.75

40 50 60





Application

1.Vegetables

2.Fruits

3.Meat

4.Seafood

5.Poultry

6.Dairy

7.Bakery

Advantage

1.High draining capacity

2.Good ventilatory

3.Easy to clean

4.Oil-Resistant

5.Heat & Cold Resistant

6.Wear-Resistant

7.Tear-Resistant

8.Acid And Alkali Resistant

9.Color optional

10.Factory direct sale price

11.Reliable quality and after-sale service

Physical and chemical properties

Polyoxymethylene (POM), also known as acetal,polyacetal, and polyformaldehyde,It is an engineering thermoplastic used in precision parts requiring high stiffness, low friction and excellent dimensional stability. As with many other synthetic polymers, it is produced by different chemical firms with slightly different formulas and sold variously by such names as Delrin, Kocetal, Ultraform, Celcon, Ramtal, Duracon, Kepital, Polypenco, Tenac and Hostaform.

POM is characterized by its high strength, hardness and rigidity to −40 °C. POM is intrinsically opaque white because of its high crystalline composition but can be produced in a variety of colors.POM has a density of 1.410–1.420 g/cm3.

Polypropylene (PP), also known as polypropene, It is a thermoplastic polymer used in a wide variety of applications. It is produced via chain-growth polymerization from the monomer propylene.

Polypropylene belongs to the group of polyolefins and is partially crystalline and non-polar. Its properties are similar to polyethylene, but it is slightly harder and more heat-resistant. It is a white, mechanically rugged material and has a high chemical resistance.

Nylon 6(PA6) or polycaprolactam is a polymer, in particular semicrystalline polyamide. Unlike most other nylons, nylon 6 is not a condensation polymer, but instead is formed by ring-opening polymerization; this makes it a special case in the comparison between condensation and addition polymers.
