Unloading movable telescopic belt conveyor

Short Description:

Telescopic belt conveyor bases on the common belt conveyors which are added telescopic mechanism. It can expand automatic in the length direction. Users can adjust buttons according to their own requirements and control the length of the conveyor at any time. It’s widely used in logistics industry to realize the automatic production of material entering and leaving warehouse or vehicle loading and unloading. On the machine equipped with automatic lifting device, the user can also control the height of the end of the conveyor at any time. Telescopic belt conveyor is mainly used in vehicle loading and unloading material transmission system with telescopic requirements.

Product Detail

Product Tags

Features At a Glance

Name
Telescopic belt conveyor
After-sale service
1 Year Video technical support, No overseas service provided
The belt material
600/800/1000mm Optional
Motor
SEW/NORD
Weight (KG)
3000KG
Carrying capacity
60kg/m²
Size
Accept customization
Power of 3 section
2.2KW/0.75KW
Power of 4 section
3.0KW/0.75KW
Transfer speed
25-45 m/min,frequency conversion adjustment
Telescopic speed
5-10m/min; frequency conversion adjustment
Stand-alone equipment noise
70dB (A), measured at a distance of 1500 from the equipment
Button settings on the front of the machine head
Forward and reverse, start-stop, and emergency stop buttons are set at the front end, and switches are required on both sides
Illumination
2 LED lights on the front
Route method
adopt plastic drag chain
Startup warning
set the buzzer, if there is a foreign object, the buzzer will sound an alarm

Application

Food and beverage

Pet bottles

Toilet papers

Cosmetics

Tobacco manufacturing

Bearings

Mechanical parts

Aluminum can.

Telescopic Conveyor Belt-1-4

Advantage

45eb4edd429f780f8dc9b54b7fe4394

It is suitable for the occasion of small load strength, and the operation is more stable.
The connecting structure makes the conveyor chain more flexible, and the same power can realize multiple steering.
The tooth shape can achieve a very small turning radius.
