Loading & Unloading Robot
Parameter
| Rated input voltage | AC380V |
| Joint drive motor type | AC servo motor |
| Loading and unloading speed | Max 1000boxes/hour |
| Conveying speed | Max 1m/s |
| Maximum load of single boxcargo | 25Kg |
| Vehicle weight | 2000Kg |
| Driving mode | Fourwheel independent drive |
| Wheel drive motor type | Brushless DC servo motor |
| Maximum moving speed of vehicle | 0.6m/s |
| compressed air | ≥0.5Mpa |
| Battery | 48V/100Ah lithium ion battery |
Advantage
Storage and logistics intelligent loading and unloading robots are mostly used for automatic loading and unloading of boxed products in the production and manufacturing industries such as tobacco and alcohol, beverages, food, dairy products, small household appliances, drugs, shoes and clothing. They mainly carry out efficient unmanned loading and unloading operations for containers, container trucks and warehouses. The core technologies of the equipment are mainly robots, automatic control, machine vision and intelligent identification.
